vStack-R-SL201-D08R/-NV
High performance
Supports 2 Intel Xeon Gen1 or Gen2 processors, each up to 205W (Scalable Sky Lake and Cascade Lake)
The processor has up to 28 cores, providing processing power that meets the high computing requirements of applications such as blockchain, cloud computing, big data and virtual computing.
The processor has up to 28 cores, providing processing power that meets the high computing requirements of applications such as blockchain, cloud computing, big data and virtual computing.
Specification
vStack-R-SL201-D08R/-NV
| Server model | vStack-R-SL201-D08R/-NV |
|---|---|
|
Processor
|
Supports 2 1st and 2nd generation Intel Xeon® processors
|
|
Chipset
|
Intel® C621
|
|
RAM
|
24 DDR4 memory slots at 2400 MHz, 2666 MHz, and 2933 MHz
|
|
Storage management
|
Internal: PCH supports RAID 0110&5 External Hbas: 12Gbps SAS HBA
|
|
Storage
|
Front panel: 8 x 3.5/2.5″ SAS/SATA/NVMe hot-swap hard drives Rear panel: 4 x 3.5″ SAS/SATA hard drives or 4 x 2.5″ SAS/SATA/U.2 hard drives with 2 2.5″ SSDS Internal memory: 2 PCIe 3.0 x4 M.2 ports, 2 SATA 7PIN slots (with SATA DOM support)
|
|
Network
|
2 x 1GbE (RJ45)
|
|
I/O ports
|
Front panel: 1 x VGA and 2 x USB3.0 Rear panel: 1 x VGA, 2 x USB3.0, 1 network management port and 2 RJ45 network ports OCP slot: 1 OCP 3.0 (PCIe x 8)
|
|
Riser1：3x PCIe 3.0 x8 or 1x PCIe 3.0 x16、1x PCIe 3.0 x8 Riser2：3x PCIe 3.0 x8 or 1xPCIe 3.0 x16、1x PCIe 3.0 x8 Riser3：1xPCIe 3.0 x8、1x PCIe 3.0 x8 (in x16 slot) or 1 x PCIe 3.0 x16 Riser4：1 x PCIe 3.0 x8、1 x PCIe 3.0 x8 (in x16 slot) or 1 xPCIe 3.0 x16 OCP：1 xOCP 3.0(PCIe 3.0 x8)
|
|
|
Power source
|
Supports 550W, 800W, 1300W, 1600W, 2000W and 2200W redundant power supplies
|
|
Cooling
|
4 fans 80 mm x 38 mm (N+1) Hot-swap redundant fans Optional 4 fans 80 mm x 56 mm (N+1) Hot-swap redundant fans
|
|
Management
|
The integrated iBMC management module supports management features such as IPMI, SOL, KVM Over IP and virtual media.
|
|
Safety
|
TPM/TCM (optional), chassis tampering detection, locking of chassis top cover
|
|
Operating system
|
Microsoft WindowServer、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
|
|
Server size
|
748 x 433.4 x 87.6 mm (L*W*H)
|
|
Operating temperature
|
Operating temperature: 5ºC - 35ºC (indoors) Storage temperature: -40ºC - 70ºC
|
